ultra bee

RANGE & PERFORMANCE Peak power of 7000 Watts on the 47kg motorcycle delivers an outstanding power to weight ratio. The torque oriented mid drive motor offers an easy and quick acceleration up to 45- 50mp/h (80km/h)

ECO MODE RANGE ESTIMATE 60 MILES @ 15MPH (100KM @ 25KM/H)

SPORT MODE (AGGRESSIVE RIDING ON TRAILS/ENDURI CIRCUITS) RANGE ESTIMATE 40KM ON FULL CHARGE

*Range is affected by many factors including rider’s weight, inclines, terrain etc.

  • 0-100%

    in 3 hrs

  • -40km/h

    sport mode range

  • -100km

    @25km/hr eco-mode
ultra bee

MOTOR Sur-Ron PCSM High Power Motor with Regen energy recovery system. Our dynamic motor has been designed for optimal power delivery and instant response time. Perfect for all types of riding from green lanes to freestyle. Whenever you need a quick, short boost or a powerful thrust, this bike is ready to deliver

DRIVE SYSTEM Coaxial Multistage Transmission featuring a primary belt (Ratio 2.217) with direct link to a secondary (ratio 3.248) motorcycle type 420 pitch chain and sprocket. This design enables a wide range of options for gearing, drive chain and aftermarket sprockets. The primary belt system uses a German Continental belt for low noise with high torque applications.

*For extreme use in sand or mud we recommend the upgrade of a primary chain and sprocket kit. (Available by order alongside further modifications).

LIGHT BEE X SPECS

  • MOTOR TYPE

    AIR-COOLED PERMANENT MAGNET SYNCHRONOUS MOTOR

  • ROTATION SPEED

    4500rpm

  • CONTROLLER TYPE

    FOC SINWAVE CONTROLLER

  • BUSBAR CURRENT

    80A

  • MAX TEMPERATURE

    100 °C

  • NOMINAL VOLT

    60V (DC)

  • NOMINAL POWER

    3KW

  • MAX POWER

    5KW

  • NOMINAL TORQUE

    80A 10.2N.m

  • PEAK TORQUE

    37.8N.m

  • GEAR RATIO

    01 : 07.6

  • TYPE OF BELT DRIVE

    BELT + GOLDEN OIL SEAL CHAIN

  • BATTERY

    60V 32A LITHIUM BATTERY WITH 176 PANASONIC CELLS

  • CHARGER

    10Ah

  • CHARGING TIME

    3-6 HOURS

  • SEAT HEIGHT

    760mm

  • FRAME MATERIAL

    NO. 6061 T4 & T6 ALUMINUM ALLOY

  • FRAME FORMING MODE

    FORGED BY 6000 TONS PRESSURE

  • FRAME WEIGHT

    7.8KG

  • FRONT FORK

    KKE BF355RC UP-SIDE-DOWN HYDRAULIC ABSORBER

LIGHT BEE X SPECS

  • REAR SHOCK ABSORBER

    KKE BR27RC

  • RIM MATERIAL AND SIZE

    ALUMINIUM ALLOY SPOKE WHEELS, FRONT/REAR 19 x 1.4

  • TIRE SIZE

    FRONT/REAR 70/100-19

  • SPEED

    25KM/H or 45KM/H (unlimited speed is 75KM/H)

  • ENDUARANCE DISTANCE

    100KM @ 20KM/H

  • BRAKE SYSTEM

    BILATERAL 4-PISTON CALIPPER HYDRAULIC DISC BRAKE

  • NET WEIGHT + BATTERY

    55KG

  • RATED LOAD

    100KG

  • MAX GRADIENT

    45°

  • BIKE SIZE

    1885mm x 780mm x 1050mm

  • MIN GROUND CLEARANCE

    270MM

  • WHEELBASE

    1265MM

  • PACKING SIZE

    1630mm*315mm*860mm/1640mm*310mm*790mm

  • GROSS WEIGHT

    WAITING

  • CONTAINER LOADING QUANTITY

    20FT CABINET, 40FT HIGH CABINET
